SWE-200M-36 200W Solar Panels
$212.25
CETL Approved for the Canadian Market with a 10/25 Year Warranty.
Key Features
- Mono crystalline modules designed for off-grid applications.
- High power output of more than 200W with efficient generating area and module efficiency up to 19.61%
- Anti-reflective and anti-soiling surface reduces power loss from dirt and dust.
- Outstanding performance in low-light irradiance environments
- Excellent mechanical load resistance: certified to withstand high wind loads (2400Pa) and snow loads (5400Pa)
Specification
| Maximum Surface Load Capacity | 2400Pa(wind) 5400Pa (snow) |
| Temperature Range | – 40 °C to + 85 °C |
| Current Temperature Coefficient | -0.292%/K |
| Temperature coefficient of Voc | -0.29%/℃ |
| Maximum System Voltage [V] | 1000 |
| Temperature coefficient of Isc | 0.05%/℃ |
Electrical characteristics at Standard Test Conditions(STC)
| Pmpp [W] | 200 |
| Isc [A] | 11.03 |
| Impp [A] | 10.16 |
| Voc [V] | 23.4 |
| Vmpp [V] | 19.7 |
| Module Efficiency | 19.61% |
| Weight | 11.2 kg |
|---|---|
| Dimensions | 150 × 68 × 3 cm |
